LABORATORIES & LICENSED SOFTWARES IN THE DEPARTMENT OF MECHANICAL ENGINEERING

  1. Workshop Laboratory.
  2. Computer Aided Engineering Drawing.
  3. Material Testing Laboratory.
  4. Mechanical Measurements & Metrology Laboratory.
  5. Foundry & Forging Laboratory.
  6. Machine Shop Laboratory.
  7. Fluid Mechanics & Machines Laboratory.
  8. Energy Laboratory.
  9. Heat Transfer Laboratory.
  10. Computer Aided Modelling & Analysis Laboratory.
  11. CIM & Automation Laboratory.
  12. Design Laboratory.
  13. M.Tech Laboratory (MPM).
  14. M.Tech Laboratory (TPE).
  15. Licensed Softwares.

WORKSHOP LABORATORY (WSL)

Sl. No.  Name of the Equipment / Tools
1  Bench Drilling Machine
2  Welding Machine
3  Power Hacksaw
4  Welding Transformer
5  Sheet metal Tools
6  Fitting Tools
7  Welding Tools

MATERIAL TESTING LABORATORY

Sl. No.  Name of the Equipment / Tools
1  Magnetic Crack Detector

 Sample Plate
2  Metallurgical microscope
3  Buffing Machine
4  Imported Microhardness Tester Model: HVS 1000B with load-range from 10gm up to 1000gm with camera and image analysis software
5  Real-Time Based Live Image Analysis Software system for metallurgical Microscope including watec japan Camera 5megapixels, grabber card, adaptor and complete software for metallurgical microscope
6 Impact Testing Machine DigitalFIE Make, Model: IT 30D
7  ROCKWELL Cum Brinell HARDNESS TESTERFIE Make, Model: RASN (B)
8  MUFFLE Furnace (12000C) with Digital PID Controller
9  Double Disc Polishing Machine DC Motor with variable Speed up to 1200 RPM
10  Analogue Torsion Testing Machine
11  Digital Fatigue Testing Machine
12  Portable Digital Ultrasonic Flaw Detector Model 44440

MECHANICAL MEASUREMENTS & METROLOGY LABORATORY

Sl. No.  Name of the Equipment / Tools
1  Drill Tool Dynamometer
2  Mill Tool Dynamometer (3” vice)
3  Lathe Tool Dynamometer
4  Temperature indicator tooltip temperature
5  Autocollimator
6  Profile projector
7  Tool maker’s microscope
8  Load cell, Digital load indicator
9  LVDT Trainer
10  Strain measurement trainer, Strain indicator, Strain gauge kit
11  Comparators: Pneumatic, Mechanical
12  Measurement of surface roughness

FOUNDRY & FORGING LABORATORY (F&F)

Sl. No.  Name of the Equipment / Tools
1  Muffle Furnace
2  Sand Washer
3  Sieve Shaker
4  Sand Rammer
5  Permeability teller
6  USS Tester
7  Digital Balance
8  Rapid Moisture Tester
9  Shatter Index
10  Muller
11  Mould Hardness Tester
12  Core Hardness Tester
13  Dewalt 14”Cut off machine

MACHINE SHOP LABORATORY

Sl. No.  Name of the Equipment / Tools
1  Azad Power Hacksaw machine
2  Kirloskar Lathe EP – 1330
3  Kirloskar Shimoga Lathes
4  Batliboi Milling machine
5  Rolex Planing machine
6  Rolex Surface Grinding machine
7  Effico Radial Drilling machine
8  Eiffco Pillar Drilling machine
9  Sager Grade – I Shaping machine 18″
10  Serovo-raj Shaping machine 12″
11  Eiffco Slotting machine
12  Kirloskar Lathe 1550
13  Batliboi BGL 350 Lathe
14  Kirloskar – MK Capstan Lathe
15  Rolex Prima Hacksaw machine
16  Bench Grinding machine 8″

FLUID MECHANICS & MACHINES LABORATORY

Sl. No.  Name of the Equipment / Tools
1  Venturi and Orifice meter setup
2  Friction in Pipes and Minor losses in Pipe fittings setup
3  Notch Calibration
4  Impact of Jet on Vanes
5  Centrifugal Pump test rig
6  Metacentric Height Ship model
7  Bernoulli’s Apparatus (With Renould’s Apparatus attachment)
8  Gear and Vane Pump test rig
9  Reciprocating Pump test rig
10  Series and Parallel pump test rig
11  Pelton Wheel Turbine
12  Francis Turbine
13  Kaplan Turbine
14  Open Orifice and Mouth Piece setup
15  Calibration of Flow nozzle
16  Performance test on Centrifugal Air Blower

ENERGY LABORATORY

Sl. No.  Name of the Equipment / Tools
1  Planimeter
2  Redwood Viscometer
3  Flashpoint Cleve land
4  Gas Test assembly
5  Cloud and Pourpoint apparatus
6  Pressure Gauge
7  Carbon residue Test
8  Drop point of Grease
9  Pento meter
10  Flashpoint apparatus
11  Say Bolt Viscometer
12  Bomb Calorimeter
13  Gas Calorimeter
14  Torsion Viscometer
15  Ring and Ball apparatus
16  Single Cylinder (2-Stroke) Petrol Engine
17  Single Cylinder (4-Stroke) Diesel Engine
18  Torque Wrench
19  Japan Socket Toolbox set
20  Air Compressor
21  Orsat Gas Analysis apparatus
22  Twin Cylinder Diesel engine Test rig (4-Stroke)
23  3HP Diesel engine (2-Stroke)
24  Horizontal Diesel engine 6HP (4-Stroke)
25  Single Cylinder Petrol engine (4-Stroke)
26  Multi Cylinder Petrol engine (4-Stroke)
27  Variable compression ratio petrol engine test rig
28  Nozzle tester
29  Single cylinder Diesel engine with Electrical loading (4-Stroke)
30  Single cylinder Petrol engine with Electrical loading (2-Stroke)
31  AVL 437 Smoke meter
32  CO/HC Gas analyzer
33  Computerized Single cylinder Diesel engine (4-Stroke)
34  Gas Cylinder (Oxygen)
35  Exhaust gas Calorimeter
36  Cut section model of Petrol engine (4-Stroke)
37  Digital panel meters for engine test rigs
38  0.5 HP Slow Speed Motor
39  Weighing Balance (Electrical)
40  Junkers Gas Calorimeter
41  Multi Cylinder Petrol Engine test rig with hydraulic dynamometer for Morse test
42  Variable Compression Ratio Petro engine test rig
43  Torsion Viscometer
44  Single Cylinder Four stroke petrol engine test rig

HEAT & MASS TRANSFER LABORATORY

Sl. No.  Name of the Equipment / Tools
1  Thermal Conductivity of a Metal Rod set up.
2  Heat Transfer Coefficient of a Composite wall set up
3  Effectiveness on a Metallic fin set up
4  Free Convection on a vertical tube set up
5  Forced Convection Flow through a Pipe set up
6  Emissivity of a Surface set up
7  Stefan Boltzmann Constant set up
8  Parallel Flow and Counter Flow Heat Exchangers set up
9  Boiling of Liquid and Condensation of Vapour apparatus
10  Vapour Compression Refrigeration test rig
11  Vapour Compression Air – Conditioner test rig
12  Transient Conduction Heat Transfer set up
13  Pebble Bed Heater
14  Fluidized Bed Chamber
15  Electrical Analogy

DESIGN LABORATORY

Sl. No.  Name of the Equipment / Tools
1  Static and Dynamic Balancing apparatus
2  Universal Governor Apparatus
3  Motorized Gyroscope
4  Whirling of Shafts
5  Journal Bearing apparatus
6  Polariscope  (Diffused Light Research)
7  Vibration setup
8  Strain Gauge

CAD / CAM LABORATORY

Sl. No.  Name  Configuration
1  Personal Computers (DELL)  Dual Core, 1GB RAM, 500 GB HDD, 17″ Monitor.
2  Personal Computers (HCL)  Core 2 Duo, 2GB RAM, 500 GB HDD, 18.5″ Monitor.
3  Personal Computers (DELL)  Core I3, 4GB RAM, 500 GB HDD, 18.5″ Monitor.
4  Workstation Computers (DELL)  Core I5, 4GB RAM, 500 GB HDD, 18.5″ Monitor.

CAED LABORATORY

Sl. No.  Name  Configuration
1  Personal Computers (DELL)  Dual Core, 1GB RAM, 500 GB HDD, 17″ Monitor.
2  Personal Computers (HCL)  Core 2 Duo, 2GB RAM, 500 GB HDD, 18.5″ Monitor.
3  Personal Computers (DELL)  Core I3, 4GB RAM, 500 GB HDD, 18.5″ Monitor.

M.TECH LABORATORY (PRODUCTION MANAGEMENT)

Sl. No.  Name  Configuration
1  Workstation Computers (DELL)  Core I5, 4GB RAM, 500 GB HDD, 18.5″ Monitor.
2  Workstation Computers (DELL – Server)  Core I7, 16GB RAM, 1TB HDD, 21″ Monitor.

M.TECH LABORATORY (THERMAL POWER ENGINEERING)

Sl. No.  Name  Configuration
1  Personal Computers (LENOVO)  Core I5, 8GB RAM, 1TB HDD, 18.5″ Monitor.

LICENSED SOFTWARES

Sl. No.  Name of the Software
1  MTAB Lathe & Mill
2  NISA V12
3  ANSYS V10.0
4  Solid Edge V19
5  AMESim Hydraulics and Pneumatics Software
6  ANSYS V12.0
7
  1. MATLAB
  2. Simulink
  3. Partial Differential Equation Toolbox
  4. SimScape
  5. Sim Mechanics
  6. Sim Hydraulics
  7. Sim Event
  8. State Flow
  9. Symbolic Math
8
  1. CAPSturn
  2. CAPSmill
  3. seeNC-Turn
  4. seeNC-Mill
  5. Ncyclo Mill
  6. Ncyclo Turn
9  Robocell V5.6
10  Autocad 2017
